SIC1369

Customized 8 x 3.0 m Lg, 1 x 1.5 m Lg, 1 x 1.0 m Lg & 2 x 0.5 m Lg x 1100 mm Overall Wide heavy duty Pallet Conveyor - Powder Coated (BLAZE BLUE). Including: 1) 8 x 3.0 m lg x 1100 mm Overall Width Heavy Duty Mild Steel Pallet conveyor and 76.00 mm Dia Galvanised rollers spaced at 150 mm pitch (20 Rollers). These rollers have 20.00 mm Diameter Mild Steel Fixed round shafts, Drilled & Tapped M12 both ends, 260/76 Series Precision bearings Assembly with 6202 z bearings and Chrome Plated End Cap.1000 mm (Approx.) Inside Frame Dimension. 2) 1 x 1.5 m lg x 1100 mm Overall Width Heavy Duty Mild Steel Pallet conveyor and 76.00 mm Dia Galvanised rollers spaced at 150 mm pitch (10 Rollers). These rollers have 20.00 mm Diameter Mild Steel Fixed round shafts, Drilled & Tapped M12 both ends, 260/76 Series Precision bearings Assembly with 6202 z bearings and Chrome Plated End Cap.1000 mm (Approx.) Inside Frame Dimension. 3) 1 x 1.0 m lg x 1100 mm Overall Width Heavy Duty Mild Steel Pallet conveyor and 76.00 mm Dia Galvanised rollers spaced at 150 mm pitch (6 Rollers). These rollers have 20.00 mm Diameter Mild Steel Fixed round shafts, Drilled & Tapped M12 both ends, 260/76 Series Precision bearings Assembly with 6202 z bearings and Chrome Plated End Cap.1000 mm (Approx.) Inside Frame Dimension. 4) 2 x 0.5 m lg x 1100 mm Overall Width Heavy Duty Mild Steel Pallet conveyor and 76.00 mm Dia Galvanised rollers spaced at 150 mm pitch (3 Rollers). These rollers have 20.00 mm Diameter Mild Steel Fixed round shafts, Drilled & Tapped M12 both ends, 260/76 Series Precision bearings Assembly with 6202 z bearings and Chrome Plated End Cap.1000 mm (Approx.) Inside Frame Dimension. NOTE: 1) The side frames are made of "C" Sections 250 mm x 50 mm x 50mm, 4.0 mm Thick Mild Steel sheet. The side frames are fixed together with 4 Nos of MS RHS welded Cross Members for extra strength. 2) Pallet conveyors & Ball Transfer Tables can install Straight on the Ground thru Dyn bolts M10. Suit holes provide on side channels.
